Lean Duplex S32304

Lean Duplex S32304





The alloy lean duplex 2304 has similar corrosion resistance properties to 316L. Furthermore, its mechanical properties i.e. yield strength, are twice those of 304/316 austenitic grades. This allows the designer to save weight, particularly for properly designed pressure vessel applications.


Chemical Analysis


Typical values (weight %)
C Cr Ni Mo N Others
0.020 23 4 0.2 0.1 S = 0.001
PREN (‰Cr+3.3‰Mo+16‰N) ≥ 24


Mechanical Properties

Tensile properties (minimum values)
°C Rp 0.2
MPa
Rp 1.0
MPa
Rm
MPa
°F YS 0.2‰
KSI
YS 1.0‰
KSI
UTS
KSI
Elongation
20 400 440 600 68 58 64 87 25
100 330 365 570 212 48 53 83 25
200 280 310 530 392 41 45 77 20
30 230 260 490 572 33 38 71 20


Density: 7,800 kg/ – 0.28 lb/in3
Interval
temper
°C
Thermal
expansion
αx10-6K-1
°C Resistivity
(µΩ cm)
Thermal
conductivity
(W.m-1.K-1)
Specific
heat
(J.kg-1.K-1)
Young
modulus
E
(GPa)
Shear
modulus
G
(GPa)
20-100 13 20 80 17 450 200 75
100 92 18 500 190 73
20-200 13.5 200 100 19 530 160 70
20-300 14 300 105 20 560 170 67


In what form is Lean Duplex S32304 available at ISHWAR STEEL CORPORATION?

  • Bar
  • Wire
  • Sheet
  • Plate
  • Forgings
  • Pipe
  • Flanges
